1.无模设计:在组底压合时，免用大底模模具，成型线及组底线通用，
降低生产成本，节省模具。
1.Mold-Free Design:During sole pressing, there is no need for outsole molds,
allowing for a universal forming and sole assembly line. This reduces
production costs and saves on mold expenses.
2.应用鞋型:常规运动鞋、休闲鞋、皮鞋、户外登山鞋、足球鞋、田径
鞋等，最大可做到50码鞋型。
2.Applicable Shoe Types:Suitable for regular sports shoes,casual shoes, leather
shoes, outdoor hiking shoes, soccer shoes, and track & field shoes, with a
maximum size of up to 50.
3.真空压合:通过真空技术，确保大底与鞋面360度无死角紧密贴合，
提升粘合强度与产品质量，非传统油压系统作动，无漏油问题，囊袋寿命可使用50万次。
3.Vacuum Pressing:Utilizes vacuum technology to ensure a 360-degree seamless
bond between the outsole and upper, enhancing adhesion strength and
product quality.Unlike traditional hydraulic systems, it eliminates oil
leakage issues, and the airbag has a lifespan of up to 500,000 cycles.
4.High-Efficiency Production:The press head position can be adjusted for
4.高效生产:大小码型体转换时，压头位置可调整，自动化程度高，减
different shoe sizes, with a high degree of automation to reduce manual
少人工干预，降低操作CT时效，提高生产效率。
intervention. This lowers operation cycle time (CT) and improves
production efficiency.
5.精准控制:配备十字定位投射灯，确保操作时放置准确，在压合过程
5. Precision Control:Equipped with a crosshair positioning projection light to
的精准度和一致性。
ensure accurate placement, enhancing precision and consistency during
the pressing process
6.节能减碳:纯电节能系统1.5KW，对比传统压机省电80%以上，优化
6.Energy Saving & Carbon Reduction:Uses a fully electric energy-saving system
能源使用，符合环保标准。
with only 1.5KW power consumption,reducing electricity usage by over
80% compared to traditional presses. Optimized energy usage meets
7.数据联网:可做数位化网路接口，将生产数据连线倒出，提高工厂大
environmental standards.
数据模型成效。
7. Data Networking:Supports digital networking interfaces for real-time production
data extraction, enhancing the effectiveness of factory big data models.
8.安全装置:机台身安装三色警示灯，压箱操作台配有光眼电栅感应装
置，有效降低工安问题，并设置防空压感应，压箱内若无
侦测到鞋子，系统不启动。
8.Safety Features:
.The machine is equipped with a three-color warning light.
.The pressing operation platform has an optical sensor safety guard to
effectively reduce workplace hazards.
.Features an anti-empty press sensor: if no shoe is detected inside the
pressing chamber, the system will not activate.
